24V 100Ah Enjoybot Battery Kit | 2-Pack Combination
- Grade-A LiFePO4 Prismatic Cells
- 100AH, 1280WH Capacity (RC @25A: 240min)
- 4000+ Cycles at 100% DOD, 10-Year Lifespan
- Built-in 100A Smart BMS, 6-Layer Protections
- 100A Max Continuous Discharge (350A 3-5s Peak Discharge)
- Expandable Up to 4P4S to Form a 48V 400Ah System
- Zero Maintenance, Environment Friendly
- IP67 Rated Waterproof and Vibration-proof
24V 100Ah Enjoybot Battery Kit | 2-Pack Combination - 12V 100Ah | Self Heating & Bluetooth (2 Packs) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Buy with Confidence
Buy with Confidence
10-Year Warranty & Professional Tech Support.
Enjoybot 24V 100Ah Battery Set
| Mechanical Specifications | ||
| 12V 100Ah | 12V 100Ah | |
| Group Size | 24 | 31 |
| Cell | Grade A LiFePO4 Prismatic Cells | Grade A LiFePO4 Prismatic Cells |
| Dimension | 10.23 x 6.61 x 8.22 in | 12.95 x 6.77 x 8.42 in |
| Weight | 22 lbs (10kg) | 23 lbs (10.8kg) |
| Terminal | M8*16mm (L) | M8*16mm (L) |
| Battery Pack Case | ABS Plastic | ABS Plastic |
| Waterproof Rating | IP67 | IP67 |
| Warranty | 10 years | 10 years |
| Feature |
Bluetooth Self-Heating Low Temp Cutoff |
Low Temp Cutoff |
| Electrical Specifications | ||
| Energy | 1280Wh | 1280Wh |
| Cycle Life | 4,000+ times @ 100% DOD | 4,000+ times @ 100% DOD |
| Max Depth of Discharge (DOD) | 100% | 100% |
| Nominal Voltage | 12.8V | 12.8V |
| Nominal/Usable Capability | 100Ah | 100Ah |
| BMS | 100A | 100A |
| Max. Continuous Charging Current | 50A | 50A |
| Max. Continuous Discharging Current | 100A | 100A |
| Peak Discharge Current | 350A (3-5 Seconds) | 350A (3-5 Seconds) |
| Max. Load /Inverter Power | 1280W | 1280W |
| Charge Voltage | 14.2V-14.6V | 14.2V-14.6V |
| Recommend Charge Current | 20A | 20A |
| Max. Batteries in Series | 4 Packs | 6 Packs |
| Ideal Max. Batteries in Parallel | 1-4 Packs | 1-4 Packs |
| Max. Batteries in Parallel | 10 Packs | 10 Packs |
| Max. Configuration | 4S4P (build 48V 400Ah battery system) | 6S4P (build 72V 400Ah battery system) |
| Charge Temperature | -4°F ~ 131°F (-20°C ~ 55°C) |
32°F ~ 122°F (0°C ~ 50°C) |
| Discharge Temperature | -4℉ ~ 140℉ (-20℃ ~ 60℃) |
-4℉ ~ 140℉ (-20℃ ~ 60℃) |
| Storage Temperature | 14℉ ~ 122℉ (-10℃ ~ 50℃) |
14℉ ~ 122℉ (-10℃ ~ 50℃) |
PACKAGE LIST
- 2* Enjoybot LiFePO4 Lithium Battery
- 4* Terminals & Caps
- 1* User Manual
Description
Description
Made by linking two of our top-tier 12V 100Ah batteries in series, giving you all-day power. Available in Group 24 or Group 31 sizes, with an IP67 rating for tough marine conditions.
Ideal for 24V trolling motors and long-lasting power in demanding environments.
* If applicable, an additional 14.6V charger can be used for balancing multiple batteries connected in series.
Intelligent automatic self-heating function activates at 32°F charging cutoff and charging resumes at 41°F, preventing cold-weather damage.
This innovative feature enables real-time tracking of voltage, capacity, and charging status, making it easier than ever to keep your battery in optimal condition.
Advanced 100A BMS with six-layer protection, supporting 100A continuous / 350A peak current output.
6S4P configuration achieves 72V 400Ah capacity, enabling flexible expansion for high-demand applications.
Payment & Shipping
- Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
- Free shipping. Orders will be shipped from the local warehouse and are estimated to arrive within 3-5 days.
Contact Us | Warranty | Return & Refund | Q&A | Manual
| SKU | EB-12100MINI-SH | EB-12100-6S |
| BCI Group | Group 24 | Group 31 |
| Dimension | 10.23 x 6.61 x 8.22 in | 12.95 x 6.77 x 8.42 in |
| Weight | 22 lbs | 23 lbs |
| Feature | Bluetooth / Self-Heating / Low Temp Cutoff | Low Temp Cutoff |
| Cell | Grade A LiFePO4 Prismatic Cells | Grade A LiFePO4 Prismatic Cells |
| Terminal | M8*16mm (L) | M8*16mm (L) |
| Battery Pack Case | ABS Plastic | ABS Plastic |
| Energy | 1280Wh | 1280Wh |
| Cycle Life | 4,000 times @ 100% DOD | 4,000 times @ 100% DOD |
| Max Depth of Discharge (DOD) | 100% | 100% |
| Nominal Voltage | 12.8V | 12.8V |
| Nominal/Usable Capability | 100Ah | 100Ah |
| BMS | 100A | 100A |
| Max. Continuous Charging Current | 50A | 50A |
| Max. Continuous Discharging Current | 100A | 100A |
| Peak Discharge Current | 350A (3-5 Seconds) | 350A (3-5 Seconds) |
| Max. Load/Inverter Power | 1280W | 1280W |
| Charge Voltage | 14.2V-14.6V | 14.2V-14.6V |
| Recommend Charge Current | 20A | 20A |
| Max. Batteries in Series | 4 Packs | 6 Packs |
| Ideal Max. Batteries in Parallel | 1-4 Packs | 1-4 Packs |
| Max. Batteries in Parallel | 10 Packs | 10 Packs |
| Max. Configuration | 4S4P (build 48V 400Ah battery system) | 6S4P (build 72V 400Ah battery system) |
| Charge Temperature | -4°F ~ 131°F (-20°C ~ 55°C) | -4°F ~ 131°F(-20°C ~ 55°C) |
| Discharge Temperature | -4℉ ~ 140℉ (-20℃ ~ 60℃) | -4℉ ~ 140℉ (-20℃ ~ 60℃) |
| Storage Temperature | 14℉ ~ 122℉ (-10℃ ~ 50℃) | 14℉ ~ 122℉ (-10℃ ~ 50℃) |
